Description

Temperature:

• Setting temperature range with humidity: +5 to +70 °C
• Setting temperature range without humidity: 0 to +70 °C
• Working temperature range with humidity: +5 (at least 20 below ambient temperature) to +70 °C
• Working temperature range without humidity: 0 (at least 20 below ambient temperature) to +70 °C
• Setting accuracy temperature 0.1 °C
• Temperature sensor 2 Pt100 sensors DIN Class A in 4-wire-circuit for mutual monitoring, taking over functions in case of an error

Humidity:

• Setting range humidity 10 – 90 % rh
• Humidity supply with distilled water from external tank by self-priming pump
• Humidification by hot steam generator
• Dehumidification by cold trap using the Peltier technology
• Setting accuracy humidity 0.5 % rh

Control Technology:

• ControlCOCKPIT TwinDISPLAY. Adaptive multifunctional digital PID-microprocessor controller with 2 high-definition TFT-color displays.
• Language setting German, English, Spanish, French, Polish, Czech, Hungarian
• Adjustable parameters temperature (Celsius or Fahrenheit), relative humidity, timer
• Timer digital backwards counter with target time setting, adjustable from 1 minute to 99 days
• Function SetpointWAIT the process time does not start until the set temperature is reached
• Calibration three freely selectable values each, temperature and humidity

Communication:

• Communication interface Ethernet LAN, USB
• Documentation program stored in case of power failure
• Programming AtmoCONTROL software on a USB stick for programming, managing and transferring programs via Ethernet interface or USB port

Safety:

• Temperature control over- and under temperature monitor TWW, protection class 3.3 or adjustable temperature limiter TWB, protection class 2, selectable on display
• AutoSAFETY additionally integrated over- and under temperature protection “ASF”, automatically following the setpoint value at a preset tolerance range, alarm in case of over- or under temperature, heating function is switched off in case of overtemperature, cooling function in case of under temperature
• Autodiagnostic system integral fault diagnostics for temperature and humidity control
• Alarm visual and acoustic

Heating Concept:

• Energy-saving Peltier heating-/cooling system integrated in the rear (heat pump principle)
