Description
Product Highlights:
• Versatility and Customization: Over 15 modification options, available in three sizes, with a customizable Ensemble Pegboard™ system.
• Advanced Safety Features: Patented SafeDraft™ Ventilation Technology, Integrated Air Filtration System, and backdraft ventilation to ensure a safe working environment.
• High-Quality Construction: Made from durable U.S.A. stainless steel, equipped with a sink on the right-hand side and backdraft ventilation.
• Technological Integration: Features OrchestraOS 2.0 touchscreen control panel, PathCam 24.1 MP Imaging Hardware, and compatibility with leading EHR systems.
• Enhanced Ergonomics: Ergorail™ Track, multiple G.F.C.I. receptacles, sliding work surfaces, and magnetic instrument bar for user convenience.
• Additional Safety Measures: Flow detection with backdraft alert, seismic anchoring points, and integrated air filtration to minimize dust and debris build-up.
Specs
• Temperature Range: 70.0±10.0°F or 21.0±6.0°C
• Relative Humidity Range: 35% – 75%
• Elevation Range: 0-2000 meters
Domestic Electrical Specification:
• Voltage/Phase/Frequency: 115v/1ph/60hz
• Circuit Requirement: (1) 15a dedicated circuit
• Full Load FLA: 7.2A
• Nominal Current: 3.2A
Export Electrical Specification:
• Voltage/Phase/Frequency: 220v/1ph/50hz
• Circuit Requirement: (1) 10a dedicated circuit
• IEC320 C13 Hospital-Grade Power Cord (three prongs, UL Listed, 14awg, 6’ length, 15A @ 115v/ 10A @ 220v)
Water Supply Range:
• Pressure: 50 -100 psi
• Flow: 6GPM minimum
• Temperature: 45 -120°F (7-48°C)
• Connections: Supply Hot/Cold water into ½” NPT Strainers
Formalin Dispensing (if equipped):
• Holding Tank Capacity: Approximately 5 Gallons
• Fill Rate: 3.0gpm
• Dispense Rate: 0.45gpm
• Maximum Work Surface Load: 200lbs or 91kg
• Ingress Protection (IP) Rating: IP40
• Workstation Configuration Weight: Range from 696-1220lbs (315-553Kg)
Height of Unit:
• Lowest Height Position: 75” (1.9m)
• Highest Elevated Position: 87” (2.2m)
• Airflow Specifications:
• Static Pressure: 0.37 inches of water column
• Total CFM: 600 CFM at 0.37” static pressure via 8” round ducts
