Ohaus Explorer™ Precision High Capacity Balance EX24001N – 24,000 g


Explorer™ Precision High Capacity Flagship Balances from OHAUS deliver the top performance in the industry for high capacity weighing applications with capacities up to 35 kg. Explorer highcapacity balances offer the same intuitive features, such as AutoCal™ and a 1 second stabilization time, with additional functions and attributes to support higher capacity weighing applications.


Modular Design:
• 5.7″ (145mm) diagonal color VGA touch screen optimizes viewing and menu navigation
• Two touchless sensors on display offer hands-free operation
• The display can be separated from the base up to 5 feet (1.5 meters) in order to fit operational needs in almost any workspace. A 27 foot (9 meter) cable is also available when additional flexibility is needed.
Superior protection in rugged or unstable environments:
• With a die-cast metal base and a 14.8″ × 12.2″ (377 × 311mm) stainless steel pan, the Explorer High Capacity is built to withstand rugged, every day use.
• 2-D Protection prevents shock and damage associated with movement and forces applied to the balance
• IP54 base enclosure protects the weighing base from damage by debris and accidental spills and splashes. (High Capacity models only)
High Capacity Accessories for Added Efficiency:
• Adjustable rolling feet option provides assistance to easily moving the balance
• Rechargeable battery option provides 10 hours of operation away from a power source
• Weigh-below hook included and can be used for density determination

Additional information

Weight 27.56 lbs
Dimensions 21.65 × 14.96 × 11.42 in

• Maximum Capacity: 24,000 g
• Readability: 0.1 g
• Readability (Certified): 1 g
• Pan Size: 14.8 in x 12.2 in (377 mm x 311 mm)
• Internal Calibration: AutoCal™ – Automatic
• Draftshield: —
• Auto Door: Not Applicable
• Auxiliary Display Model: Available as an Accessory
• Battery Life: Not Applicable
• Communication: Ethernet (Available as an Accessory); USB (Included); RS232 (Included)
• Dimensions: 17.44 in x 4.7 in x 14.9 in (443 mm x 120 mm x 377 mm) (LxHxW)
• Display: Full-color 5.7 in VGA, touch screen
• Inuse cover: Included
• Legal for Trade: NTEP Certified; Measurement Canada Approved
• Linearity ±: 0.2 g
• Minimum Weight (USP, 0.1%, typical): 210 g
• Net Weight: 22 lb (10 kg)
• Pan Construction: Stainless Steel
• Power: AC Adapter (Included)
• Repeatability, typical: 0.1 g
• Stabilization Time: 1 s
• Tare Range: To capacity by subtraction
• Units of Measurement: Singapore Tael; Ounce Troy; Pennyweight; Kilogram; Grain; Tical; Custom; Milligram; Newton; Momme; Taiwan Tael; Baht; Gram; Hong Kong Tael; Pound; Tola; Mesghal; Carat; Ounce
• Working Environment: 50°F – 86°F, 85%RH, non-condensing (10°C – 30°C, 85%RH, non-condensing)
