Description
• Adjustable LED light
• Upgraded Hinges
• Variable speed controller
• Acrylic hood material
• Hour counter
• Pressure reading
• No costly ducting or venting
• No permitting issues for venting outside of the building (ie. EPA air sampling)
• Adaptable (mobility and ease in change of layout)
• Environmentally friendly
• Significant energy cost savings
Note: There are some low molecular weight substances that may not be appropriate for a ductless fume hood. In addition, certain high workload conditions may require external ducting.
• Hood Dimensions:
30” O.D.: 24″D x 32″W x 25″H , I.D.: 23.5″D x 30″W x 24″H
40” O.D: 24″D x 42″W x 25″H, I.D.: 23.5″D x 40″W x 24″H
50” O.D: 24″D x 52″W x 25″H, I.D.: 23.5″D x 50″W x 24″H
60” O.D: 24″D x 62″W x 25″H, I.D.: 23.5″D x 60″W x 24″H
70” O.D: 24″D x 72W” x 25″H, I.D.: 23.5″D x 70″W x 24″H
• Hood Material:
– Sides: .250″ White Acrylic
– Base: .500″ White High Density Polyethylene
– Top: .500″ Clear Polycarbonate
• Front Windows:
0.250″ Clear Polycarbonate
• Motor:
Fractional Horsepower
• Total Weight:
30” 40” Approx. 100 lbs.
50” Approx. 125 lbs.
60” Approx. 140 lbs.
70” Approx. 155 lbs
• Available Filter Efficiencies:
HEPA Filter – Up to 99.97% efficient on particles down to 0.3 microns
ASHRAE Filter – Up to 95% efficient on particles down to 0.5 microns
ULPA Filter – Up to 99.9995% efficient on particles down to 0.12 microns
Activated Carbon & Specialty-Blended Filters – Efficiency varies per chemical.
• Blower Dimensions:
13″ L x 13″ W x 14.5″ H
• Approximate Inlet Velocities:
Pre-filter & 99.97% HEPA Filter – 100 FPM
Pre-filter & Heavy-duty Carbon Filter – 60 FPM
• Electrical:
115/1/60, 2 amps
220/1/50, .75 amps (not on 30” model)
• Sound Level:
61 to 66 dba (Blower Speed: Low to High)
• Max Operating Temperature:
Not to exceed 170 degrees Fahrenheit
• Patented Design:
U.S. PATENT #5,843,197
Limited two-year warranty from date of shipment on defects due to materials or workmanship
